Logitech Rally Bar Mini

Clear
SKU: N/A Category: Tag:

Logitech Rally Bar Mini

DIMENSIONS

Height: 3.6 in (91.4 mm)
Width: 2.36 ft (719 mm)
Depth: 3.98 in (101 mm)
Weight: 4.88 lb (4.03 kg

TECHNICAL SPECIFICATIONS

Camera

Resolution: 4K, 1440p, 1080p, 900p, 720p, and SD at 30fps

Pan: Motorized ±25°

Tilt: Motorized ±15°

Zoom: 4X HD digital zoom

Diagonal Field of View: 120°

Horizontal Field of View: 113°

Vertical Field of View: 80.7°

Total Room Coverage (field of view + pan and tilt): 163° horizontal x 110° vertical

Speakers

Woofer: 2.76 in (70 mm)

Mid-range: 2x / 1.5 in

Output: 90 dB SPL @1W, 99dB SPL @8.0W, both +/-2dB at ½ meter

Sensitivity: 86+/-2 dB SPL at 1W, ½ meter

THD: 1kHz < 2%

Speaker Sampling Rate: 48 kHz

Microphones

Frequency response: 90Hz – 16kHz

Sensitivity: >-36dBFS +/-1 dB @ 1Pa

Microphone data rate output: 48 kHz

Pickup Range: 15 ft / 4.5m

Beamforming Elements: Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams

Audio processing: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector)

Noise suppression: AI filter

Add-on Mics: Supports up to 2 additional Rally Mic Pods

RightSense™ Technologies

RightLight™: Renders natural skin tones for each participant

RightSight: Maintains persistent room awareness and detects human figures to auto-frame participants.

RightSound: Distinguishes speech from other sounds to auto-level voices while suppressing background noise and echo

Interfaces

HDMI Out: 2

HDMI In: 1

USB 3.0: 3x Type A, 1x Type C

Network: 0.04oz (1 g)0/100/1G Ethernet

WiFi: 802.11a/b/g/n/ac (MIMO)

External Mic Input: Yes (proprietary input supports optional Rally Mic Pod, Rally Mic Pod Hub, and Rally Mic Pod Extension Cable)

Remote Control: Bluetooth® Low Energy

Power & Cables

Power supply: Auto-sensing

Operating Voltage/Power: 100-240V, 19V, 4.74A

Power Supply Dimensions: 5.00 in (127 mm ) x 2.01 in (51 mm) x 1.18 in (30 mm)

DC Cable: 5 ft (1.5 m)

AC Cable: 3.28 ft (1 m)

HDMI 1.4 Cable: 7 ft (2 m)

USB A to USB C 3.0 Cable: 7.2 ft (2.2 m)

Environmental

Operating Temperature: 0 to 40°C

Storage Temperature: -40 to 70°C

Humidity: 10 to 95%

BTU/hr: 57 idle, 64 in meeting

Security

Full Disk Encryption: AES-128

Data Encryption: Symmetric Keys, PKI

Device Identity: Protected by device attestation

Device Access: Authenticated using API

Key Protection: Arm TrustZone, RPMP

Certifications & Compatibility

Certifications: Zoom Certified, Certified for Microsoft Teams as a USB device. Contact the manufacturer for additional information on pending and granted certifications

Compatibility: Plug and play USB connectivity with virtually any video conferencing application

Appliance mode: Supports compatible video conferencing software in appliance mode (no PC required), including Zoom Rooms Appliances

Certification pending for Microsoft Teams Rooms on Android and additional video conferencing platforms.

GENERAL SPECIFICATIONS

Built-in Components: 6 beamforming microphones, PTZ camera, 3 speakers, AI Viewfinder, cable management & retention system, table stand, Logitech CollabOS platform

Enclosure: All-in-one enclosure with integrated table stand and patented speaker suspension system to eliminate vibration-induced camera shake and audio interference

Device Management: Logitech Sync

Displays Supported: 2

Display Resolution: Up to 4K

PACKAGE CONTENTS

Rally Bar Mini

Power supply

AC power cord

HDMI cable

USB cable

Remote control Lens caps for main lens and AI Viewfinder

User documentation

WARRANTY INFORMATION

Standard: 2-year limited hardware warranty included
Extended: Additional one-year extended warranty available at the time of hardware purchase.
Colour

Graphite, White
