Poly Studio Premium USB Video Bar

• DIMENSIONS

• • • Unit dimensions:
      • 105 mm x 700 mm x 70 mm = 4.2” x 27.3” x 2.8” (HxWxD) without stand
      • 156 mm x 700 mm x 70 mm = 6.2” x 27.3” x 2.8” (HxWxD) with stand
    • Weight:
      • 5 lbs 2.6 oz (2342 g) without stand
      • 6 lbs 4.7 oz (2856 g) with stand
    • Remote control dimensions:
      • 183 mm x 40 mm x 19 mm = 7.2” x 1.6” x .75” (HxWxD)

• POWER REQUIREMENTS

  • 12VDC/5A @ 100~240VAC, 50/60 Hz

• PACKAGE INCLUDES

  • Poly Studio
  • Remote control with 2 AAA batteries
  • Power adapter
  • 5 m USB 2.0 cable (Type-C to Type-A)
  • Wall mount kit
  • Setup sheet

• OPTIONAL ACCESSORIES

  • Expansion microphone
  • Display mount

• CAMERA

  • 120-degree FOV
  • UHD 2160p (4K) capture resolution
  • Automatic people framing & speaker tracking
  • 5x zoom / EPTZ
  • 2 camera presets

• AUDIO

  • Poly Acoustic Clarity technology provides full-duplex conversations, acoustic echo cancellation and background noise suppression
  • Poly NoiseBlock technology
  • Poly Acoustic Fence technology
  • Mute/unmute controls
  • Stereo microphones:
    • 6-element beamforming microphone array
    • 12 ft pickup range
    • 120 Hz–16 kHz frequency response
  • Stereo speakers:
    • 100 Hz–20 KHz frequency response
    • Output = 90 dB @ 0.5m

• INTERFACES

  • 1x USB 3.0 Type-C port (with 2.0 compatibility)
  • Power connector
  • Optional external microphone
  • 3.5 mm stereo Audio In
  • Kensington security lock
  • 802.11ac Wi-Fi wireless networking for manageability; IEEE 802.11a/b/g/n compatible
  • Bluetooth® 4.2

• APPLICATION COMPATIBILITY

  • Compatible with any application that supports standard USB audio and video drivers, including but not limited to:
    • Certified for Microsoft Teams and Skype for Business
    • Zoom Certified
    • LogMeIn GoToMeeting®
    • BlueJeans Network
    • Google Hangouts™ communication platform
    • Amazon Chime
    • Cisco Webex®
    • VidyoDesktop™
    • Polycom RealPresence Desktop

• SECURITY

  • 802.1x support
  • Certification management

• MANAGEABILITY (VIA WI-FI)

  • Companion App (running on Win/Mac PC connected to device)
  • RealPresence Resource Manager
  • Device Management Service

• WARRANTY INFORMATION

  • 1-year limited hardware warranty

• ENVIRONMENTAL

  • Operating temperature: 32–104°F (0–40°C)
  • Relative humidity: 5–95%, noncondensing
  • Storage temperature: -13–160°F (-25°–70°C)
